Nbudata akpaaka na ebutu ụlọ elu ọkụ mkpanaka

The Automatic Loading and Unloading Mobile Lighting Tower nwere nrụnye agbakwunyere akpaghị aka na nhazi nbudata, na-ewepụ mkpa cranes, forklifts, ma ọ bụ igwe inyeaka ndị ọzọ. Ọ nwere ike ịda ngwa ngwa, gbasaa, mpịaji, ma chekwaa onwe ya na-eji naanị nhazi nke ya. Ụgbọ njem ya na-adaba adaba na ntinye ọrụ nke ọma na saịtị na-ebelata ike mmadụ na oge nkwadebe.

Uru ndị bụ isi

Ibu ngwa ngwa na ntinye onwe ya

Sistemụ nbudata na nbudata akpaka arụnyere

Enweghị akụrụngwa ebuli mpụga achọrọ

Arụ ọrụ otu onye maka njem na nhazi

Deployment time ≤ 180 seconds

High-Performance 360° Lighting

4 × 1000W LED oriọna dị elu

360° mkpuchi ọkụ na-agbanwe agbanwe

Igwe ọkụ dị elu ruo mita 120

Luminous flux ≥ 380,000 lm

Ìhè kwụsiri ike, nke na-egbukepụ egbukepụ maka ịrụ ọrụ abalị

Strong Outdoor Adaptability

IP67 waterproof lamp heads

Wind resistance up to Level 8

Ọdịdị na-eguzogide uzuzu na corrosion

Na-arụ ọrụ na mmiri ozuzo, snow, ájá, na oke okpomọkụ

Long Runtime and Flexible Power

Honda 4-stroke generator (5-5.5kW)

Oge na-aga n'ihu na-arụ ọrụ ruo awa 25

Ọnọdụ ike abụọ: generator ma ọ bụ 220V mains ọkọnọ

Smart Operation System

Ogwe njikwa LCD + ikuku anya ikuku (≥120m)

Adjustable mast height up to 7.3m

Fast lifting: ≤50s up / ≤35s down

Nchekwa na mfe ọrụ interface

Technical Parameters

1. Rated Voltage: AC 220V, 50Hz

2. Lamp Head Power: 4 × 1000W LED ìhè isi iyi

3. Iluminance: Mgbe isi oriọna dị na 90 ° n'ala,

ọkụ ga-adị karịa 6000 Lx na 20 mita site na etiti ọkụ,

more than 1000 Lx at 50 meters,

na ihe karịrị 200 Lx na 120 mita.

4. Generator Power: 5～5.5kW

5. Na-ebuli ọnọdụ nke Ụlọ elu ọkụ: Pneumatic

6. Maximum Lifting Height: 7.3m

7. Klas nchekwa isi oriọna: IP67

8. Ụdị mmalite: mmalite ntuziaka + mmalite eletrik

9. Oge na-arụ ọrụ na-aga n'ihu: awa 25

10. Oge ibuli: Na-ebili ≤ 50s / ibelata ≤ 35s

11. Oke ngbanwe isi oriọna: kwụ ọtọ 0–135° / kwụ ọtọ 0–360°

12. Generator Set: Honda, 4-stroke, ikuku jụrụ oyi

13. Displacement: 389CC

14. Mmanụ ụgbọala: 1.7L / h; Ike tank mmanụ: 45L

15. Generator mmepụta Voltage: AC 220V, 50Hz

16. Total Weight: 600KG

7. Overall Dimensions:

Deployed: ≤ 2500×1500×7300mm

Stored: ≤ 1800×1400×2500mm

18. Nchekwa ọkụ ọkụ: 2×28W

19. Tower Loading and Unloading Time: ≤ 180s

20. Ihe mkpuchi ọkụ ọkụ: 120m

21. Mgbanwe nke isi oriọna na ibuli ogwe osisi nwere ike ịchịkwa site na ngosi LCD na njikwa ikuku ikuku; anya njikwa anya · 120m.

Performance Features

1. Isi ụlọ nke Automatic Loading na Unloading Mobile Lighting Tower na-eji usoro mkpọchi mechie ma mechaa ya na mkpuchi ntụ ntụ iji chebe ihe niile dị n'ime. Modul njikwa injin nwere ọgụgụ isi na-enye nleba anya zuru oke na nchebe dị irè maka injin ahụ, na-eme ka mmezi kwa ụbọchị. A na-etinye ihe nkedo na-akpụ akpụ anọ kwụ ọtọ na ala maka mmegharị mgbanwe.

2. Isi ọkụ ọkụ na-anabata 4 × 1000W LED ìhè isi iyi, na-ebuga nchapụta dị elu na oke mkpuchi dị iche iche na ìhè ogologo ogologo na nke dị mkpirikpi. Ndụ ọrụ isi iyi ọkụ karịrị awa 10,000, na-eme ka ọ dabara nke ọma maka ọkụ ọrụ dị n'èzí buru ibu.

3. Ụlọ elu ahụ dabara na pneumatic ebuli mast mere nke 6063 aluminum alloy na ike anodized elu ọgwụgwọ maka magburu onwe corrosion iguzogide, na a kacha elu elu nke 7.3 mita. Isi oriọna anọ ahụ na-akwado ntụgharị ọkụ eletrik kwụ ọtọ site na 0° ruo 135° na 360° ngbanwe akụkụ kwụ ọtọ, na-enweta mkpuchi saịtị zuru oke yana radius ọkụ na-erughị mita 120.

4. Kwadoro site na generator set, unit nwere ike na-arụ ọrụ na-aga n'ihu maka 25 awa na mmanụ ụgbọala tank zuru ezu. Enwere ike ijikọ ya na ọkụ ọkụ 220V AC maka ọkụ ogologo oge ebe ọkụ eletrik dị na obodo dị.

5. N'ịbụ onye na-arụ ọrụ na-arụ ọrụ na-arụ ọrụ na-arụ ọrụ na-arụ ọrụ na-arụ ọrụ na njikwa ntuziaka, ngwaọrụ ahụ na-arụ ọrụ dị mfe, nchekwa na ntụkwasị obi.

6. Na a kọmpat n'ozuzu Ọdịdị na ike ịrụ ọrụ, ụlọ elu na-onwem na anọ agbara eletriki push mkpanaka support ụkwụ, na-enyere ndị isi unit na-integrally weliri ihe karịrị 1000 mm. Ọ na-enye nkwado kwụsiri ike na nke ziri ezi na ebe a na-ewu ụlọ na-enweghị isi, na-arụ ọrụ nke ọma n'okpuru ọnọdụ ọjọọ na ọnọdụ ihu igwe, wee rute n'ọkwa 8 nguzogide ifufe.

7. The kacha structural imewe ana achi achi mfe ije na njem. Ọ na-akwado ibunye onwe ya na ibutu n'elu akwa akwa gwongworo, na-egosipụta echiche imewe mmadụ.

8. Mkpokọta ọkụ ọkụ nke isi oriọna: ≥380,000 lm; Ọkwa mkpọtụ: n'okpuru ọrụ nkịtị, ụda arụ ọrụ tụrụ na mita 7 n'akụkụ injin ahụ abụghị ihe karịrị 62 dB.

9. A na-etinye ihe ọkụ ọkụ nke 2 × 28W n'akụkụ isi ihe, na-egosipụta ezigbo mmiri na-adịghị na uzuzu.

Scope of Application

Nke a Automatic Loading and Unloading Mobile Lighting Tower kwesịrị ekwesị maka ụdị ọnọdụ dị iche iche ma na-egbo mkpa maka nnukwu mpaghara, ọkụ ọkụ dị elu n'ọtụtụ ubi. Ọ na-emetụta ọrụ dị iche iche nnukwu ihe owuwu, ọrụ Ngwuputa, nchọpụta ubi na ọrụ mgbasawanye ụlọ ọrụ, na-enye ọkụ zuru oke maka ọrụ dịgasị iche iche n'abalị ma ọ bụ na ọnọdụ ọkụ dị ala iji hụ na arụmọrụ ụlọ na nchekwa ọrụ.

Ka ọ dị ugbu a, ọ na-eje ozi dị ka ngwaọrụ ọkụ dị mkpa maka ọrụ nnapụta mberede. A na-eji ya eme ihe n'ọtụtụ ebe na nhazi na nrụzi mberede nke ike, nkwurịta okwu na ụlọ ọrụ okporo ụzọ, na-ahụ maka saịtị nke ihe mberede mberede, mgbochi ide mmiri na ọgụ idei mmiri, yana nnapụta ọdachi na enyemaka. Ọ na-ebunye ọkụ mberede nnukwu mpaghara kwụsiri ike iji kwado ndị otu ihe mberede na-arụ ọrụ nnapụta na ijikwa ihe egwu nke ọma.
